Custom Driveshafts with Slip Yoke
Find below your complete custom driveshaft with slip yoke, every driveshaft arrives balanced and ready for install. These driveshafts are built to your custom specifications including length, universal joint series and material. Steel or aluminum we provide the highest quality driveshaft for your application. All driveshafts come with free shipping.
Completely Customizable
- Pick your driveshaft below and tell us your custom length.
- Add any compatible differential hardware or a flange if required.
- Tell us if you need any additional modifications.
|
Order Forms: |
If you have any questions we are here to help: CHAT | PHONE (574)287-9650 | CONTACT US
Custom Driveshafts with Slip Yoke
Custom Driveshaft & Slip Yoke - 5" Al. 7290, Tremec TKX, 31 Spline, 1.688" Barrel OD (Sku: 5A1330_7290-S)
Custom Driveshaft & Slip Yoke | 5A1330_7290-S
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 31
- Barrel Diameter: 1.688"
- Series: 7290
Transmission Model:
,
Tremec TKX
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 31
- Barrel Diameter: 1.688"
- Series: 7290
Transmission Model:
,
Tremec TKX
Custom Driveshaft & Slip Yoke - 5" Al. 7290, GM 32 Spline (Short) (Sku: 5A1330_7290-P(short))
Custom Driveshaft & Slip Yoke | 5A1330_7290-P(short)
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 7290
Transmission Model:
,
4L80E (Short)
,
BorgWarner T10
,
M20
,
M21
,
M22
,
Richmond
,
TH-400 (Short)
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 7290
Transmission Model:
,
4L80E (Short)
,
BorgWarner T10
,
M20
,
M21
,
M22
,
Richmond
,
TH-400 (Short)
Custom Driveshaft & Slip Yoke - 5" Al. 7290, GM 32 Spline (Long) (Sku: 5A1330_7290-P(long))
Custom Driveshaft & Slip Yoke | 5A1330_7290-P(long)
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 7290
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 7290
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
Custom Driveshaft & Slip Yoke - 5" Al. 7290, GM 27 Spline (Sku: 5A3R_7290-L)
Custom Driveshaft & Slip Yoke | 5A3R_7290-L
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 27
- Barrel Diameter: 1.500"
- Series: 7290
Transmission Model:
,
200-R4
,
4L60E
,
700-R4
,
M21
,
Powerglide
,
T-5
,
T-56
,
TH-350
Transfer Case Model:
,
NP231
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 27
- Barrel Diameter: 1.500"
- Series: 7290
Transmission Model:
,
200-R4
,
4L60E
,
700-R4
,
M21
,
Powerglide
,
T-5
,
T-56
,
TH-350
Transfer Case Model:
,
NP231
Custom Driveshaft & Slip Yoke - 5" Al. 7290, Ford 31 Spline, 1.886" Barrel OD (Sku: 5A1330_7290-K)
Custom Driveshaft & Slip Yoke | 5A1330_7290-K
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 31
- Barrel Diameter: 1.886"
- Series: 7290
Transmission Model:
,
4R100W
,
A4LE
,
E4OS
Transfer Case Model:
,
BW1345
,
BW1356
,
BW4406
,
BW4417
,
BW4418
,
BW4419
,
NP208
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 31
- Barrel Diameter: 1.886"
- Series: 7290
Transmission Model:
,
4R100W
,
A4LE
,
E4OS
Transfer Case Model:
,
BW1345
,
BW1356
,
BW4406
,
BW4417
,
BW4418
,
BW4419
,
NP208
Custom Driveshaft & Slip Yoke - 5" Al. 7290, Ford 31 Spline, 1.688" Barrel OD (Sku: 5A1330_7290-J)
Custom Driveshaft & Slip Yoke | 5A1330_7290-J
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 31
- Barrel Diameter: 1.688"
- Series: 7290
Transmission Model:
,
C6
,
E4OD
,
FMX
,
T45
,
T46
,
T46 Magnum
,
TKO-500
,
TKO-600
,
Toploader (31 Spline)
,
Tremec
,
ZF
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 31
- Barrel Diameter: 1.688"
- Series: 7290
Transmission Model:
,
C6
,
E4OD
,
FMX
,
T45
,
T46
,
T46 Magnum
,
TKO-500
,
TKO-600
,
Toploader (31 Spline)
,
Tremec
,
ZF
Custom Driveshaft & Slip Yoke - 5" Al. 7290, Ford 28 Spline, 1.6" Barrel OD (SKU: 5A1330_7290-G)
Custom Driveshaft & Slip Yoke | 5A1330_7290-G
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 28
- Barrel Diameter: 1.600"
- Series: 7290
Transmission Model:
,
4R70
,
4R70W
,
4R75
,
AODE
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 28
- Barrel Diameter: 1.600"
- Series: 7290
Transmission Model:
,
4R70
,
4R70W
,
4R75
,
AODE
Custom Driveshaft & Slip Yoke - 5" Al. 7290, Ford 28 Spline, 1.5" Barrel OD (SKU: 5A1330_7290-F(Short))
Custom Driveshaft & Slip Yoke | 5A1330_7290-F(Short)
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 28
- Barrel Diameter: 1.500"
- Series: 7290
Transmission Model:
,
AOD
,
C4
,
T-10
,
T-5
,
Toploader (28 Spline)
,
Tremec TR3550
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 28
- Barrel Diameter: 1.500"
- Series: 7290
Transmission Model:
,
AOD
,
C4
,
T-10
,
T-5
,
Toploader (28 Spline)
,
Tremec TR3550
Custom Driveshaft & Slip Yoke - 5" Al. 7290, Ford 25 Spline (Sku: 5A1330_7290-H)
Custom Driveshaft & Slip Yoke | 5A1330_7290-H
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 25
- Barrel Diameter: 1.375"
- Series: 7290
Transmission Model:
,
5R55E
,
A4LD
,
C3
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 25
- Barrel Diameter: 1.375"
- Series: 7290
Transmission Model:
,
5R55E
,
A4LD
,
C3
Custom Driveshaft & Slip Yoke - 5" Al. 7290, Chrysler 30 Spline (Sku: 5A7290-Ea)
Custom Driveshaft & Slip Yoke | 5A7290-Ea
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 30
- Barrel Diameter: 1.681"
- Series: 7290
Transmission Model:
,
45RFE
,
47RE
,
47RH
,
48DG8
,
48RE
,
545DGQ
,
545RHE
,
65RFE
,
727
,
A500
,
A518
,
A833
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 30
- Barrel Diameter: 1.681"
- Series: 7290
Transmission Model:
,
45RFE
,
47RE
,
47RH
,
48DG8
,
48RE
,
545DGQ
,
545RHE
,
65RFE
,
727
,
A500
,
A518
,
A833
Custom Driveshaft & Slip Yoke - 5" Al. 7290, Chrysler 30 Spline (SKU: 5A1330_7290-Eb)
Custom Driveshaft & Slip Yoke | 5A1330_7290-Eb
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 30
- Barrel Diameter: 1.681"
- Series: 7290
Transmission Model:
,
45RFE
,
47RE
,
47RH
,
48DG8
,
48RE
,
545DGQ
,
545RHE
,
65RFE
,
A518
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 30
- Barrel Diameter: 1.681"
- Series: 7290
Transmission Model:
,
45RFE
,
47RE
,
47RH
,
48DG8
,
48RE
,
545DGQ
,
545RHE
,
65RFE
,
A518
Custom Driveshaft & Slip Yoke - 5" Al. 7260, Ford 31 Spline, 1.886" Barrel OD (Sku: 5A1330_7260-K)
Custom Driveshaft & Slip Yoke | 5A1330_7260-K
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 31
- Barrel Diameter: 1.886"
- Series: 7260
Transmission Model:
,
4R100W
,
A4LE
,
E4OS
Transfer Case Model:
,
BW1345
,
BW1356
,
BW4406
,
BW4417
,
BW4418
,
BW4419
,
NP208
- Tube Dia.: 5.0" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 31
- Barrel Diameter: 1.886"
- Series: 7260
Transmission Model:
,
4R100W
,
A4LE
,
E4OS
Transfer Case Model:
,
BW1345
,
BW1356
,
BW4406
,
BW4417
,
BW4418
,
BW4419
,
NP208
