Spicer/Dana
Spicer 6C-5X U-Joint
Universal Joint Kit | 6C-5X
- Series: 1550 X 6C/62N
- Grease: Greasable
- HWT / OSR
- Between Bolts: 1.375" X 1.689"
- Lock Up: 4.969" X 5.531"
- Brand: Spicer/Dana
- Series: 1550 X 6C/62N
- Grease: Greasable
- HWT / OSR
- Between Bolts: 1.375" X 1.689"
- Lock Up: 4.969" X 5.531"
- Brand: Spicer/Dana
Spicer 70-28-27 Weld Yoke / Tube Yoke
Tube Yoke (Weld Yoke) | 70-28-27
- Series: 1550 1555 SPL 70
- Type: Outside Snap Ring
- Tube OD: 3.500"
- Material: Steel
- Series: 1550 1555 SPL 70
- Type: Outside Snap Ring
- Tube OD: 3.500"
- Material: Steel
Spicer 70-3-41X Slip Yoke
Mid Shaft Slip Yoke | 70-3-41X
- Series: SPL 70
- Spline Count: 27
- Grease: Greasable
- U-joint: 1.375" X 5.25"
- Length: 9.279"
- Outside Snap Ring
- Series: SPL 70
- Spline Count: 27
- U-joint: 1.375" X 5.25"
- Length: 9.279"
- Outside Snap Ring
Spicer 70-4-01789-1X End Yoke (Obsolete)
End Yoke | 70-4-01789-1X
- Series: ∙ 1550 ∙ 1555 ∙ SPL 70
- Spline Count: 34
- Spline OD: 1.790”
- Bore Length: 2.750”
- Cap OD: 1.375"
- Yoke Span: 4.969"
- Hub Dia.: 2.562”
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1550 , 1555 , SPL 70
- Spline Count: 34
- Spline OD: 1.790”
- Bore Length: 2.750”
- Cap OD: 1.375"
- Yoke Span: 4.969"
- Hub Dia.: 2.562”
- Style: Outside Snap Ring
- Rear Axle Type:
Spicer 8-3-411KX Slip Yoke Assembly
Mid Shaft Slip Yoke | 8-3-411KX
- Series: 1880
- Spline Count: 16
- X 8.094"
- Full Round
- Series: 1880
- Spline Count: 16
- X 8.094"
- Full Round
Spicer 8-3-431KX Slip Yoke Assembly
Mid Shaft Slip Yoke | 8-3-431KX
- Series: 1880
- Spline Count: 24
- X 8.094"
- Full Round
- Series: 1880
- Spline Count: 24
- X 8.094"
- Full Round
Spicer 8-68-13 Plug
Hardware | 8-68-13
- Outside Dia: 3.06"
- Vent Hole Dia: 0.13"
- Slip Yoke Plug
- Qty: 1
- Material: Steel
- Type: Flat
- Outside Dia: 3.06"
- Vent Hole Dia: 0.13"
- Slip Yoke Plug
- Qty: 1
- Material: Steel
- Type: Flat
Spicer 8-82-171-1 Yoke Shaft
Yoke Shaft | 8-82-171-1
Driveshaft Yoke Shaft Series: 1880 U-Joint Cap Diameter (D): 2.188 Inch U-Joint Width (E): 8.094 Inch Style: Full Round Major Spline Diameter: 4.156 Inch Centerline To End Of Spline (K): 7.219 Inch...
Spicer 90-2-19 Flange Yoke
Flange Yoke | 90-2-19
- Series: SPL 90
- Pilot Dia.: 6.624" M
- Outside Snap Ring
- U-joint: 1.625" X 4.957"
- Bolt Circle: 6.124"
- Manufacturer: Spicer/Dana
- Series: SPL 90
- Pilot Dia.: 6.624" M
- Outside Snap Ring
- Cap: 1.625" Width: 4.957"
- Bolt Circle: 6.124"
- Manufacturer: Spicer/Dana
Spicer 90-2-39-1 Flange Yoke
Flange Yoke | 90-2-39-1
- Series: SPL 90
- Pilot Dia.: 6.438" M
- Outside Snap Ring
- U-joint: 1.625" X 4.957"
- Bolt Circle: 7.250"
- Manufacturer: Spicer/Dana
- Series: SPL 90
- Pilot Dia.: 6.438" M
- Outside Snap Ring
- Cap: 1.625" Width: 4.957"
- Bolt Circle: 7.250"
- Manufacturer: Spicer/Dana
Spicer 90-3-41X Slip Yoke Assembly
Mid Shaft Slip Yoke | 90-3-41X
- Series: SPL 90
- Spline Count: 30
- U-joint: 1.625" X 4.957"
- Outside Snap Ring
- Series: SPL 90
- Spline Count: 30
- U-joint: 1.625" X 4.957"
- Outside Snap Ring
Spicer 90-4-11-1 End Yoke
End Yoke | 90-4-11-1
- Series: ∙ SPL 90
- Spline Count: 34
- Spline OD: 1.790"
- Bore Length: 2.250"
- Cap OD: 1.625"
- Yoke Span: 4.957"
- Hub Dia.: 2.190"
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , SPL 90
- Spline Count: 34
- Spline OD: 1.790"
- Bore Length: 2.250"
- Cap OD: 1.625"
- Yoke Span: 4.957"
- Hub Dia.: 2.190"
- Style: Outside Snap Ring
- Rear Axle Type:
