Spicer 5-1330-1X U-Joint

Vendor: Spicer/Dana, Sku: 5-1330-1X

Previous Product | Next Product
Product Description

Spicer Drive Shaft U-Joint 5-1330-1X

 This part is drop shipped from the manufacturer and will ship at the earliest available time. Average time to ship is several weeks from when you place the order. You can contact Action Machine Inc. to confirm product availability and for an estimated time of arrival. CHAT | (574)287-9650

Alternate Part Number:
Spicer 5-1330X U-Joint (non-greasable)



Spicer 10® Series U-Joints, from the Most Trusted Name in Drivelines.
Spicer 10® Series u-joints are the standard for premium performance in the driveshaft market. Spicer products are manufactured using statistically controlled processes to ensure you get the same high-quality part every time.

Bearing Cups
Heat-treated for strength; precision ground and case-hardened for durability.

Zerks
Allow for relubricating at regular intervals to help extend the life of the part.

Seal and Bearings
The process of precision grinding the seal and bearing surfaces helps to improve the life of the seal and bearing.

Journal Cross
Forged with high-quality steel, precision heat-treating and case-hardening to very specific levels, ensuring optimal and consistent strength and durability.

Type: Outside Snap Ring Style (OSR)
OEM Series: 1330/SPL25
Bearing Cap Diameter: 1.062 Inch (26.974 mm) (D1)
1.062 Inch (26.974 mm) (D2)
Lock Up / Length:
*Snap Ring to Snap Ring 		3.625 Inch (92.1 mm) (G1)
3.625 Inch (92.1 mm) (G2)
Grease Type: Greasable
Snap Rings Included: Yes
Material: Steel & Rubber
Package: Each / Qty 1

VMRS: 024002046

U-joint Diagram

Compatible Parts:
Spicer 2-70-18X U-Joint Strap Kit
Spicer 2-94-28X U-Bolt Kit


inside snap ring
Part Number Interchange
Spicer Part # 5-1330-1X
Series
 SPICER 1330
Moog/Precision 254, 270, 354
Neapco 2-4800, 2-4801, 2-0790, 2-4800G
Duralast 2-4800DL, 2-4801DL
SKF UJ254, UJ270, UJ354


More Product Information:

Sku: 5-1330-1X
Vendor: Spicer/Dana
$24.47
Maximum quantity available reached.

DETAILS

OEM Series:		 1330
Manufacturer: Spicer/Dana
Greasable: Greasable
Snap Ring Type: Outside Snap Ring
Manufacturer Part Number: 5-1330-1X
Bearing Cap Diameter: 1.062"
Lock Up: 3.625"
OEM/Alternate Part Number:
023913250676
.
