AAM 40065702 End Yoke

Vendor: AAM, Sku: 40065702

Product Description

Drive Shaft End Yoke / Pinion Yoke


The differential end yoke / pinion yoke transfers the power from the driveshaft to the pinion through a u-joint at the end of the driveshaft. This allows the driveshaft to spin while the rear differential travels up and down with the suspension.




t

*



End/Pinion Yoke Specifications
This flange yoke dose have a speedy sleeve and no dampener.

Manufacturer: AAM
Manufacturer Part Number: 40082168
U-Joint Series: 1485 (1480)
Style: Outside Snap Ring
U-Joint Cap Diameter (A): 1.375 Inch
U-Joint Width (B): 4.188 Inch
End Yoke Length(C) :
- Center Line to End of Spline
3.900 Inch
Hub Diameter (D): 2.370 Inch
Spline Diameter (E):
- From Farthest Point to Farthest Point
1.590 Inch
Number of Splines (F): 30
Bore Length (G): 1.630 Inch
Rear Axle Type:
AAM 10.5 Inch, AAM 11.5 Inch


How to Measure a Driveshaft Slip Yoke.

Application for the GM 10.5" & 11.5"

Sierra:
2001-2010
Yukon:
2001-2010
Silverado:
2001-2010
Avalanche:
2001-2010
Tahoe:
2001-2010
Suburban:
2001-2010
Escalade:
2001-2010



****


This part is compatible with:
SKU 26060977 : 10.5 Inch Pinion Sleeve
SKU 26064030 : 10.5 Inch /11 Inch Pinion Seal
SKU 1-0030 : Bearing Strap Kit

Alternate Part Numbers:
AAM 74007479 End Yoke
AAM 40007479 End Yoke
AAM 40082168 End Yoke

PTI 4804-301 End Yoke
PTI 4804-30 End Yoke (Without Dampener)
GM 12471499 End Yoke

For assistance measuring your end yoke/pinion yoke you can use our:
End Yoke Measuring Guide

If you have any questions we are here to help:  CHAT | CONTACT US | (574)287-9650

Sku: 40065702
Vendor: AAM
$103.00
