Spicer 4-4-4111-1X End Yoke

Vendor: Spicer/Dana, Sku: 4-4-4111-1X

Product Description

Drive Shaft End Yoke / Differential Yoke


The differential end yoke / pinion yoke transfers the power from the driveshaft to the pinion through a u-joint at the end of the driveshaft. This allows the driveshaft to spin while the rear differential travels up and down with the suspension.




t

*



End/Pinion Yoke Specifications

Manufacturer: Spicer/Dana
Manufacturer Part Number: 4-4-4111-1X
U-Joint Series: 1550
Style: Outside Snap Ring
U-Joint Cap Diameter (A): 1.375 Inch
U-Joint Width (B): 4.964 Inch
End Yoke Length(C) :
- Center Line to End of Spline
4.700 Inch
Hub Diameter (D): 2.500 Inch
Spline Diameter (E):
- From Farthest Point to Farthest Point
1.774 Inch
Number of Splines (F): 34
Bore Length (G): 2.260 Inch

VMRS: 022003072


How to Measure a Driveshaft Slip Yoke.

Application:




Vehicle Information:





****


This part is compatible with:
Spicer SPL70X U-Joint

For assistance measuring your end yoke/pinion yoke you can use our:
End Yoke Measuring Guide
